HP Compaq 6005 Pro Product End-Of-Life Disassembly Instructions

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Gas Discharge Lamps
-
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
PSU (Acbel ,Delta , Liteon ) and System fan
containing brominated flame retardants,
Mother board
TBC
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
-
0
Components, parts and materials containing
refractory ceramic fibers
-
0
Components, parts and materials containing
radioactive substances
-
0
1.3 Markings for plastic parts greater than 25 grams
Plastic Part Name
Plastic Part
Description
Weight (grams)
ISO 11469:2000 Plastic
Part Mark
Optional:
Main Bezel
Main bezel of desktop
product
89g
>ABS<
Fan Duct
System fan holder of
desktop product
58.7g
>PC+ABS FR(40)<
Fan Holder
Fan holder of desktop
product
44.9
>PC+ABS FR(40)<
System Fan
Frame_ADDA
System Fan Frame of
desktop product
45g
>PBT-GF30 FR(17)<
System Fan
Frame_DELTA
System Fan Frame of
desktop product
45g
>PBT-GF30-FR(17)<
Chassis Stand
Chassis Stand of
desktop product
78.0g
>ABS<
DC Fan Frame_ADDA
DC Fan Frame of
desktop or tower
product
40g
>PBT-GF30 FR(17)<
DC Fan Frame_DELTA
DC Fan Frame of
desktop or tower
product
40g
>PBT-GF30-FR(17)<
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Description #1 Philips Screw Driver
100mm
Description #2 Diagonal cutting pliers
130mm
Description #3 Long nose pliers
NA
Description #4 Unsolder tool
NA
Description #5 Solder machine
230mm
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:

HP Compaq 6005 Pro Specifications

General

Processor cache	2 MB
Processor cores	2
Processor model	B26
Processor family	AMD Athlon II X2
Processor frequency	3.2 GHz
Processor cache type	L2
Processor manufacturer	AMD
Number of processors installed	1
Operating system installed	Windows 7 Professional
Compatible operating systems	FreeDOS
Operating system architecture	32-bit
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	320 GB
Audio system	HD
Product type	PC
Motherboard chipset	AMD 785G
Memory slots	4x DIMM
Internal memory	2 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 2 GB
Networking features	Gigabit Ethernet
Floppy drive installed	No
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Discrete graphics card model	AMD Radeon HD 4200
Display diagonal	24 \
Display brightness	300 cd/m²
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Viewing angle, horizontal	160 °
USB 2.0 ports quantity	6
Parallel ports quantity	-
Firewire (IEEE 1394) ports	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Power supply input voltage	110 - 240 V
Power supply input frequency	50 - 60 Hz

Weight and Dimensions

Depth	430 mm
Width	176 mm
Height	377 mm
Weight	9300 g
