Item Description Spare part number
(1) Display assemblies (include 2 WLAN antenna transceivers and cables)
14.1-inch, WXGA BrightView display assembly for use only with computer models equipped
with discrete graphics subsystem memory
456598-001
14.1-inch, WXGA display assembly for use only with computer models equipped with
discrete graphics subsystem memory
456597-001
14.1-inch, WXGA BrightView display assembly for use only with computer models equipped
with UMA graphics subsystem memory
456596-001
14.1-inch, WXGA display assembly for use only with computer models equipped with UMA
graphics subsystem memory
456595-001
Display internal components:
Display bezel 456620-001
Display enclosure (includes 2 WLAN antenna transceivers and cables) 456621-001
Display hinges (includes left and right hinges) 456619-001
Display inverter 456618-001
(2) Switch cover (includes LED board and cable) 456592-001
(3) Keyboards
For use in Japan 456624-291
For use in South Korea 456624-AD1
For use in Taiwan 456624-AB1
For use in Thailand 456624-281
For use in the United States 456624-001
(4) Speaker 456593-001
(5) Top cover 456599-001
Plastics Kit (see
Plastics Kit on page 20 for more Plastics Kit spare part information): 456614-001
(6a) ExpressCard slot bezel
(6b) WLAN module compartment cover
(6c) Memory module compartment cover
(6d) Hard drive bay cover
TouchPad components
(7a) TouchPad bracket (included in the TouchPad Miscellaneous Kit, which also includes the
TouchPad board cable and TouchPad button board actuators, which are not illustrated)
456602-001
(7b) TouchPad board 456600-001
(8) Fan 431312-001
(9) TouchPad button board (includes cable) 456601-001
(10) System boards (includes replacement thermal material and the ExpressCard assembly)
For use only with computer models equipped with Intel Core 2 Duo processors and discrete
graphics subsystem (includes 128-MB DDR2 discrete graphics system memory)
456613-001
Computer major components 15
