TouchPad board and TouchPad button board
Description Spare part number
TouchPad board 456600-001
TouchPad button board (includes cable) 456601-001
TouchPad Miscellaneous Kit (includes TouchPad board cable, TouchPad bracket, and TouchPad
button board actuators)
456602-001
Before removing the TouchPad board and TouchPad button board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 37).
5. Remove the following components:
a. Hard drive (see
Hard drive on page 38)
b. Optical drive (see
Optical drive on page 45)
c. Keyboard (see
Switch cover and keyboard on page 47)
d. Switch cover (see
Switch cover and keyboard on page 47)
e. Speaker (see
Speaker on page 51)
f. Display lid switch module (see
Display lid switch module on page 52)
g. Display assembly (see
Display assembly on page 53)
h. Top cover (see
Top cover on page 58)
Remove the TouchPad board and TouchPad button board:
1. Turn the top cover upside down, with the front toward you.
2. Release the ZIF connectors on the TouchPad button board (1) and TouchPad board (2) to which
the TouchPad board cable is connected.
3. Disconnect and remove the TouchPad board cable (3).
Component replacement procedures 61
