Reverse this procedure to install the WLAN module.
Memory module
Description Spare part number
2048-MB (PC2-5300, 667-MHz, DDR2) 417506-001
1024-MB (PC2-5300, 667-MHz, DDR2) 414046-001
512-MB (PC2-5300, 667-MHz, DDR2) 414045-001
Before removing the memory module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 37).
Remove the memory module:
1. Loosen the Phillips PM2.0×5.0 captive screw (1) that secures the memory module compartment
cover to the computer.
2. Lift the front edge of the cover (2), swing it up and back, and remove the cover. The memory
module compartment cover is included in the Plastics Kit, spare part number 456614-001.
3. Spread the retaining tabs (1) on each side of the memory module slot to release the memory
module. (The edge of the module opposite the slot rises away from the computer.)
Component replacement procedures 43
