7
Screw listing
This section provides specification and reference information for the screws and screw locks used in the
computer. All screws and screw locks listed in this section are available in the Screw Kit, spare part number
443906-001.
Torx T8M2.5×7.0 screw
Color Quantity Length Thread Head diameter
Black 2 7.0 mm 2.5 mm 5.0 mm
Where used: 2 screws that secure the bottom edge of the display bezel to the display assembly
ENWW Torx T8M2.5×7.0 screw 117
