Torx T8M2.5×9.0 screw
Color Quantity Length Thread Head diameter
Black 23 9.0 mm 2.5 mm 5.0 mm
Where used:
(1) One screw that secures the optical drive to the computer
(2) Four screws that secure the display assembly to the computer
ENWW Torx T8M2.5×9.0 screw 123
