13. If it is necessary to replace the Bluetooth module cable, disconnect the cable (2) from the system
board and remove the cable from the opening (3) in the base enclosure.
NOTE: The Bluetooth module cable is included with the Bluetooth module, spare part numbers
398393-002 (for use with all computer models in all countries and regions except Japan and Asia/
Pacific) and 450066-001 (for use with all computer models in all countries and regions except Japan
and Asia/Pacific), and is also available in the Cable Kit, spare part number 443887-001.
14. If it is necessary to replace the modem module cable, disconnect the cable (1) from the modem
module and the system board (2), and remove the modem connector (3) from the clip built into the
base enclosure.
NOTE: The modem module cable is available in the Cable Kit, spare part number 443887-001.
Reverse this procedure to install the top cover, microphone, Bluetooth module cable, and modem module
cable.
84 Chapter 4 Removal and replacement procedures ENWW
