1–4 Quick Setup & Getting Started Guide
Quick Setup
Step 3: Connect External Devices
Connect the monitor, mouse, keyboard, and network cables.
Rear Panel Connectors (Arrangement of connectors may vary by
model.)
Ä
CAUTION: Do not add optional hardware devices to your personal
computer until the operating system is successfully installed. Doing so may
cause errors and may prevent the operating system from installing
properly.
1 Power cord connector
2 Voltage select switch
3 Mouse connector
4 Keyboard connector
5 Universal Serial Bus (USB)
connectors
6 Serial connector
7 Parallel port connector
8 Monitor connector
9 Audio/Line-in connector
- Headphone/Line-out
connector
q Microphone connector
w Gameport connector
