HP Compaq dc5100 MT User Manual

Hardware Reference Guide www.hp.com 2–19
Hardware Upgrades
To remove, replace, or add an expansion card.
1. Turn off the computer properly through the operating system and
turn off any external devices. Disconnect the power cord from the
power outlet and disconnect any external devices.
2. Remove the access panel and lay the computer on its side with the
opening to internal parts where the access panel was located
facing up.
3. On the rear of the computer, a sliding slot cover lock secures the
expansion card brackets and expansion slot covers in place.
Remove the thumbscrew that holds the slot cover lock in place 1
and slide the slot cover lock away from the brackets 2 so that
they are no longer secured by the lock.
Releasing the Slot Cover Lock
376292-001.book Page 19 Friday, February 18, 2005 2:42 PM

HP Compaq dc5100 MT Specifications

General

Memory	Up to 4 GB DDR2 SDRAM
Memory Slots	4 DIMM slots
Hard Drive	Up to 160 GB SATA
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Operating System	Windows XP Professional
Form Factor	Microtower
Processor	Intel Pentium 4
Chipset	Intel 915G
Optical Drive	CD-ROM, DVD-ROM
Graphics	Intel GMA 950
Audio	Integrated AC'97 audio
Expansion Slots	1 PCI Express x16, 3 PCI
Ports	1 serial, 1 parallel, audio in/out
