HP Compaq dc5800 Quickspecs

Other TIA/EIA 602 standard AT command set
Integrated DTE interface with speeds of up to 115.2 Kbps, parallel 16550a
UART-compatible interface
Optional ring wakeup signal
Operating Temperature 32° to 158° F (0° to 70° C)
Operating Humidity 20% to 90%, non-condensing
Power Requires a 3.3-V auxiliary power rail on PCI bus
Uses only one PCI load (i.e., one grant/request pair), one shared IRQ, one
electrical load
Chipset Agere Systems SV92PL – Integrated PCI interface with 5-V tolerant buffers
and CardBus support
Dimensions (L X H) Complies with PCI low profile specifications-6.7 x 2.3 in (17.0 x 5.8 cm) and
supports high- and low-profile brackets
Connection Single RJ-11 connector
Other Features Digital line protection, call progress monitoring via on-board piezo device,
support for high profile and low profile brackets, PnP ID support
Safety UL recognized to UL 1950, 3
rd
edition (U.S. and Canada); IEC 950 (TUV, NEMKO,
DEMKO, SEMKO); CE Mark, EC 950 (TUV, NEMKO, DEMKO, SEMKO, CE mark
EMC FCC Part 15, IC ES003, EN 55022, 3rd edition, EN 55024, annex A, EN 61000-4-
6, EN 61000-4-8
Telecom FCC Part 68, IC-CS-03 (Canada); Worldwide PTT approvals
Not available in Korea or the Republic of South Africa.
Health Bare PCB material compliant to 94V-0 or better (marked as such)
Other PC 2001 compliant, PCI version 2.3, WHQL approved; ACPI compliant
LSI PCIe x1 56K
International SoftModem
Data Transmission Technology speeds: 56,000 Kbps maximum downstream data, controllerless
NOTE: 56 Kbps technology refers to download speeds only and requires
compatible modems at server sites. Other conditions may limit modem speed.
FCC limitations allow a maximum of 53 Kbps during download transmissions.
Data Speeds (Upload only) 33,600/31,200/28,800/26,400/21,600/19,200/
16,800/14,400/12,000/9,600/7,200/4,800/2,400/1,200/300
Data Standards ITU-T V.90, ITU-T, ITU-T V.34, V.44, V.42, V.42bis21, V.32bis, Bell 212A, and
Bell 103
Fax Speeds 14,400/12,000/9,600/7,200/4,800/2,400/1,200/300 b/s
Fax Mode Capabilities ITU-T T.31 class 1 FAX, V. 17, V.29, V.27ter, and V.21 Channel 2
Error Correction and Data
Compression
V.44, 42bis, V.42 and MNP2-5
Power Management PCI Bus Power Management Interface Specification (PCI-PM) Revision 1.2,
Appendix A. D0, D3hot, and D3cold. Wake on Ring state when in D3cold. If the
power management event (PME) feature is enabled in D3cold, a modem can
wake the system via WAKE# (WAKEN) or beacon. Meets PCI Express 1.1
standard.
Upgradeability Driver upgradeable for future enhancements
QuickSpecs
HP Compaq dc5800 Business PC
Technical Specifications - Communications
DA - 12863 North America — Version 27 — October 28, 2009 Page 29

HP Compaq dc5800 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Total storage capacity	250 GB
Audio system	High Definition Audio
Product type	PC
Drive bays	2 external 5.25 inch, 1 external 3.5 inch 2 internal 3.5 inch
Driver LAN	Microsoft Windows XP, Microsoft Windows Vista, FreeDos, Linux
LightScribe	Yes
Upgrade type	Windows Vista capable
Keyboard type	HP PS/2 Standard Keyboard
Audio included	Integrated High Definition audio with ADI1884 codec, microphone and headphone front ports, line-out and line-in rear ports, multistreaming capable, internal PC speaker
Diskette drive	Optional
Expansion slots	1 full-height PCI, 1 full-height PCI Express x16, 2 full-height PCI Express x1
Pointing device	HP PS/2 2-Button Optical Scroll Mouse
Power management	Operating Voltage Range: 90 – 264 VAC; Rated Voltage Range: 100 – 240 VAC; Rated Line Frequency: 50/60 Hz; Operating Line Frequency Range: 47 – 63 Hz; Rated Input Current 80 Plus: 2.5 A; Current Leakage (NFPA 99): \u003C 275 µA; System Heat Dissipation 80 Plus: Typical 315 btu/hr (79 kg-cal/hr), Maximum 1575 btu/hr (397 kg-cal/hr; Power Supply Fan: Variable speed fan, Power Consumption in ES Mode – Suspend to RAM (S3) (Instantly Available PC): \u003C4 W
Security features	Kensington Lock
Power requirements	Input voltage 90 – 264 / 100 – 240 VAC, 50/60 Hz, 47 – 63 Hz, active PFC optional (External 80% High Efficiency) Operating Voltage Range: 90 – 264 VAC; Rated Voltage Range: 100 – 240 VAC; Rated Line Frequency: 50/60 Hz; Operating Line Frequency Range: 47 – 63 Hz; Rated Input Current 80 Plus: 2.5 A; Current Leakage (NFPA 99): \u003C 275 µA; System Heat Dissipation 80 Plus: Typical 315 btu/hr (79 kg-cal/hr), Maximum 1575 btu/hr (397 kg-cal/hr; Power Supply Fan: Variable speed fan, Power Consumption in ES Mode – Suspend to RAM (S3) (Instantly Available PC): \u003C4 W
External drive bays	2x 5.25\
Networking features	Gigabit Ethernet
Video card features	3D/2D Controller: support is fully compliant with Microsoft standard API such as Microsoft DirectX9, DirectXVA, VMR9, GDI/GDI+; OpenGL 1.4.; Integrated VGA Controller; integrated 350 MHz RAMDAC; 400 MHz Controller Clock Speed; Overlay Planes: Single overlay support with 5x3 filtering; Maximum Color Depth: 32 bits/pixel; Multi-display Support: 2 displays can be supported via the motherboard's VGA connectors and SDVO/ADD2 option Intel Graphics Media Accelerator 3100 \u003C85 Hz @ 1920x1440, 75 Hz @ 2048x1536
Acoustic power emissions	IDLE (Fixed disk drive spinning): LWAd = 3.8 Bels; FIXED DISK (Random write): LWAd = 3.9 Bels
Non-operating relative humidity (non-condensing)	5 - 90 %
Bundled software	On some models only (not included with FreeDOS): HP ProtectTools Security Solutions, HP Backup and Recovery Manager, HP Insight Diagnostics (available via HP Backup and Recovery Manager), HP Software Agent, HP Total Care Advisor, HP Client Configuration Manager, HP Client Manager for Altiris, HP SoftPaq Download Manager, HP Client Catalog for Microsoft SMS, HP Systems Software Manager, Computer Setup Utility, Altiris Out-of-Band Management Solution, McAfee AntiVirus trial version, Roxio DigitalMedia Plus 7.2/Easy Media Creator 9 Optional preloaded software, only for certain configurations: PDF Complete, Computrace for Desktops, Verdiem Surveyor agent, InterVideo WinDVD 5.0, Microsoft Office 2007 Basic, Microsoft Office 2007 Professional, Microsoft Office 2007 Small Business, Microsoft Internet Explorer with AOL Toolbar
Applications supported	Windows Vista Premium ready
Operating system installed	Windows Vista Business
Compatible operating systems	FreeDOS
Optional operating system supplied	Windows XP Professional
I/O ports	Rear: 6 USB 2.0, 1 serial port, 1 optional serial port, 1 optional parallel port, 2 PS/2, 1 RJ-45, 1 VGA, audio in/out; Front: 2 USB 2.0, audio ports
Serial ports quantity	1
USB 2.0 ports quantity	8
Parallel ports quantity	0
Chassis type	Micro Tower
Country of origin	China
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 9144 m
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Discrete graphics card model	Intel® GMA 3100
Maximum graphics card memory	0.256 GB
On-board graphics card model	Not available
Power consumption (typical)	300 W
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	428 mm
Width	176 mm
Height	377 mm
Weight	8900 g
Package weight	4450 g
