HP Compaq dc5800

DVI ADD2 Graphics
1
Models HP ADD2 SDVO DVI-D Out Adapter
Form Factor Low-profile card
DVI-D Connector Digital connection only
Dual Head Support Yes, when used with the integrated VGA connector
Display Devices
Supported
HP L1740
HP L1940T
HP L2045W
HP LP1965
NOTE: These graphics adapters offer optimal performance with any display that meets applicable VESA
standards.
Color Depth All modes support 8-bpp, 16-bpp, and 24-bpp color depths
Host Interface Connector Mechanically compliant with PCI-E standard
Complies with the Intel ADD2 and Intel Serial Digital Video Output (SDVO)
specifications
Dot Clock 165 MHz maximum
Display Modes Supports display modes that require up to 165-MHz bandwidth on the link, as
shown in the following table.
Resolution 60-Hz LCD 60-Hz 75-Hz 85-Hz
Blanking 5% reduced GTF GTF GTF
640 x 480 VGA Yes Yes Yes Yes
800 x 600 SVGA Yes Yes Yes Yes
1024 x 768 XGA Yes Yes Yes Yes
1280 x 1024 SXGA Yes Yes No No
1600 x 1200 UXGA Yes Yes No No
ATI Radeon HD 3470
(256MB SH) PCIe x16
Graphics Card
Bus type PCI Express (x16 lanes)
Maximum vertical refresh
rate
85 Hz
Display support Integrated 400 MHz RAMDAC
Display max resolution 2560x1600 digital, 2048 x 1536 analog
Board display options Supports two displays via the DisplayPort and DVI connectors
Board configuration Specification Description
Graphics Chip RV620
Core clock 750 MHz
Memory clock 500 MHz
Frame buffer 256 MB DDR2, 64 bit wide
Languages supported 24 languages: English, Arabic, Chinese Simplified, Chinese Traditional,
Czechoslovakian, Danish, Dutch, Finnish, French, German, Greek, Hebrew,
Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian,
Spanish, Swedish, Thai, Turkish
Operating systems
support
Windows Vista Business 64 * , Windows Vista Business 32 * , Windows Vista
Home Basic 32 * , Windows XP Professional or Windows XP Home 32 * .
QuickSpecs
HP Compaq dc5800 Business PC
Technical Specifications - Graphics
DA - 12863 North America — Version 27 — October 28, 2009 Page 32
