HP Compaq dc5800

ATI Radeon HD 3470 (256MB SH) PCIe x16 Graphics Card display resolutions and refresh rates
NOTE: Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP
Resolution
Maximum Refresh Rate (Hz)
Analog Connection Digital Connection
640x480 85 60
800x600 85 60
1024x768 85 60
1280x720 85 60
1280x1024 85 60
1440x900 75 60
1600x1200 85 60
1680x1050 75 60
1920x1080 85 60-R
1920x1200 85 60-R
1920x1440 85 N/A
2048x1536 75 N/A
2560x1600 N/A 60 *
* Only supported when using a dual-link DVI or DP connection
NOTE: 60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital connections.
NVIDIA Quadro NVS 290
256MB PCIe Dual Head
Form Factor Low Profile
Bus Type PCIe x16
Memory 256 MB 400MHz DDR2 SDRAM unified frame buffer, Z-buffer and Texture
storage
Connector DMS-59, includes DMS-59 to Dual VGA cable
Display Resolution
Support
Dual integrated analog display controllers supporting up to two analog
displays at 2048x1536 @ 85Hz on both displays or dual digital displays at
1920x1200 (single-link).
NVIEW advanced multi-display desktop and application management
seamlessly integrated into Microsoft Windows
RAMDAC Integrated dual 400MHz
Color planes 32-bit color buffer
Overlay planes Hardware supported
nView architecture Advanced multi-display desktop & application management seamlessly
integrated into Microsoft Windows.
Multi-Monitor support Dual monitor support
DVI support DMS-59 (to dual DVI-SL)
High-definition Video
Processor (HDVP)
Full-screen, full-frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-
2Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling
QuickSpecs
HP Compaq dc5800 Business PC
Technical Specifications - Graphics
DA - 12863 North America — Version 27 — October 28, 2009 Page 34
