HP Compaq dc5800

* Only supported when using a dual-link DVI or DP connection
NOTE: 60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital connections
NVIDIA GeForce 8400 GS
(256 MB DH) PCIe x1
Graphics Controller
Bus type PCIe x1
Maximum vertical refresh
rate
85 Hz
Display support Integrated 400 MHz RAMDAC
Display max resolution 2048 x 1536 (analog), 2560 x 1600 (digital)
Input/Output connectors DMS59 (DMS-59 port supports Dual VGA or Dual DVII connections)
TV-out (4 pin S-video)
Board display options DMS59 + TV
DMS59 supports either 2 VGA displays with the included cable or 2 DVII
displays with optional
HP DMS59 DVI Dual-head Connector Cable kit #DL139A
TV connector is a 4-pin mini-DIN S-video connector
Board configuration Specification Description
Graphics Chip NVIDIA GeForce 8400 GS
Core clock 460 MHz
Memory clock 200 MHz
Frame buffer 256 MB DDR2
Languages supported 24 languages: English, Arabic, Chinese Simplified, Chinese Traditional,
Czechoslovakian, Danish, Dutch, Finnish, French, German, Greek, Hebrew,
Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian,
Spanish, Swedish, Thai, Turkish
System memory 1GB of system memory required
Core power 25 W (Max board power)
NVIDIA GeForce 8400 GS (256 MB DH) PCIe x1 Graphics Controller display resolutions and refresh rates
NOTE : Other resolutions may be available but are not recommended as they may not have been tested and qualified by HP.
Resolution
Maximum Refresh Rate (Hz)
Analog Connection Digital Connection
640x480 85 60
800x600 85 60
1024x768 85 60
1280x720 85 60
1280x1024 85 60
1440x900 75 60
1600x1200 85 60
1680x1050 75 60
1920x1080 85 60-R
1920x1200 85 60-R
1920x1440 85 N/A
2048x1536 75 N/A
2560x1600 N/A N/A
QuickSpecs
HP Compaq dc5800 Business PC
Technical Specifications - Graphics
DA - 12863 North America — Version 27 — October 28, 2009 Page 36
