HP Compaq dc5800 Quickspecs

This product is 93% recyclable when properly disposed of at end of life.
Packaging Materials Corrugated Paper 1700 g
EPE Foam 138 g
LDPE Bag 50 g
The EPE foam packaging material is made from 30 to 60% industrial recycled content.
The corrugated paper packaging materials contains at least 80% post consumer recycled content.
Small Form Factor, Minitower
RoHS Compliance Hewlett-Packard is committed to compliance with all applicable environmental laws and regulations,
including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed
compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis. By July 1,
2006, RoHS substances were virtually eliminated (virtually = to levels below legal limits) for all HP
electronic products subject to the RoHS Directive, except where it is widely recognized that there is no
technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
Material Usage This product does not contain any of the following substances in excess of regulatory limits (refer to the
HP General Specification for the Environment at:
http://www.hp.com/hpinfo/globalcitizenship/environment/
supplychain/gen_specifications.html ):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel – finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging HP follows these guidelines to decrease the environmental impact of product packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in packaging materials.
Use readily recyclable packaging materials such as paper and corrugated materials.
QuickSpecs
HP Compaq dc5800 Business PC
Technical Specifications - Environmental Data
DA - 12863 North America — Version 27 — October 28, 2009 Page 52

HP Compaq dc5800 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Total storage capacity	250 GB
Audio system	High Definition Audio
Product type	PC
Drive bays	2 external 5.25 inch, 1 external 3.5 inch 2 internal 3.5 inch
Driver LAN	Microsoft Windows XP, Microsoft Windows Vista, FreeDos, Linux
LightScribe	Yes
Upgrade type	Windows Vista capable
Keyboard type	HP PS/2 Standard Keyboard
Audio included	Integrated High Definition audio with ADI1884 codec, microphone and headphone front ports, line-out and line-in rear ports, multistreaming capable, internal PC speaker
Diskette drive	Optional
Expansion slots	1 full-height PCI, 1 full-height PCI Express x16, 2 full-height PCI Express x1
Pointing device	HP PS/2 2-Button Optical Scroll Mouse
Power management	Operating Voltage Range: 90 – 264 VAC; Rated Voltage Range: 100 – 240 VAC; Rated Line Frequency: 50/60 Hz; Operating Line Frequency Range: 47 – 63 Hz; Rated Input Current 80 Plus: 2.5 A; Current Leakage (NFPA 99): \u003C 275 µA; System Heat Dissipation 80 Plus: Typical 315 btu/hr (79 kg-cal/hr), Maximum 1575 btu/hr (397 kg-cal/hr; Power Supply Fan: Variable speed fan, Power Consumption in ES Mode – Suspend to RAM (S3) (Instantly Available PC): \u003C4 W
Security features	Kensington Lock
Power requirements	Input voltage 90 – 264 / 100 – 240 VAC, 50/60 Hz, 47 – 63 Hz, active PFC optional (External 80% High Efficiency) Operating Voltage Range: 90 – 264 VAC; Rated Voltage Range: 100 – 240 VAC; Rated Line Frequency: 50/60 Hz; Operating Line Frequency Range: 47 – 63 Hz; Rated Input Current 80 Plus: 2.5 A; Current Leakage (NFPA 99): \u003C 275 µA; System Heat Dissipation 80 Plus: Typical 315 btu/hr (79 kg-cal/hr), Maximum 1575 btu/hr (397 kg-cal/hr; Power Supply Fan: Variable speed fan, Power Consumption in ES Mode – Suspend to RAM (S3) (Instantly Available PC): \u003C4 W
External drive bays	2x 5.25\
Networking features	Gigabit Ethernet
Video card features	3D/2D Controller: support is fully compliant with Microsoft standard API such as Microsoft DirectX9, DirectXVA, VMR9, GDI/GDI+; OpenGL 1.4.; Integrated VGA Controller; integrated 350 MHz RAMDAC; 400 MHz Controller Clock Speed; Overlay Planes: Single overlay support with 5x3 filtering; Maximum Color Depth: 32 bits/pixel; Multi-display Support: 2 displays can be supported via the motherboard's VGA connectors and SDVO/ADD2 option Intel Graphics Media Accelerator 3100 \u003C85 Hz @ 1920x1440, 75 Hz @ 2048x1536
Acoustic power emissions	IDLE (Fixed disk drive spinning): LWAd = 3.8 Bels; FIXED DISK (Random write): LWAd = 3.9 Bels
Non-operating relative humidity (non-condensing)	5 - 90 %
Bundled software	On some models only (not included with FreeDOS): HP ProtectTools Security Solutions, HP Backup and Recovery Manager, HP Insight Diagnostics (available via HP Backup and Recovery Manager), HP Software Agent, HP Total Care Advisor, HP Client Configuration Manager, HP Client Manager for Altiris, HP SoftPaq Download Manager, HP Client Catalog for Microsoft SMS, HP Systems Software Manager, Computer Setup Utility, Altiris Out-of-Band Management Solution, McAfee AntiVirus trial version, Roxio DigitalMedia Plus 7.2/Easy Media Creator 9 Optional preloaded software, only for certain configurations: PDF Complete, Computrace for Desktops, Verdiem Surveyor agent, InterVideo WinDVD 5.0, Microsoft Office 2007 Basic, Microsoft Office 2007 Professional, Microsoft Office 2007 Small Business, Microsoft Internet Explorer with AOL Toolbar
Applications supported	Windows Vista Premium ready
Operating system installed	Windows Vista Business
Compatible operating systems	FreeDOS
Optional operating system supplied	Windows XP Professional
I/O ports	Rear: 6 USB 2.0, 1 serial port, 1 optional serial port, 1 optional parallel port, 2 PS/2, 1 RJ-45, 1 VGA, audio in/out; Front: 2 USB 2.0, audio ports
Serial ports quantity	1
USB 2.0 ports quantity	8
Parallel ports quantity	0
Chassis type	Micro Tower
Country of origin	China
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 9144 m
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Discrete graphics card model	Intel® GMA 3100
Maximum graphics card memory	0.256 GB
On-board graphics card model	Not available
Power consumption (typical)	300 W
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	428 mm
Width	176 mm
Height	377 mm
Weight	8900 g
Package weight	4450 g
