HP Compaq dc5800

Microtower Small Form Factor
Chassis Dimensions
(H x W x D)
14.85 x 6.95 x 16.85 in
(37.72 x 17.65 x 42.80 cm)
3.95 x 13.3 x 14.9 in
(10.03 x 33.78 x 37.85 cm)
Optional Tower Stand
Dimensions
(H x W x D)
N/A 1.05 x 6.95 x 7.83 in
(26.75 x 176.46 x 198.87 mm)
System weight* 19.75 lb (8.96 kg) 17.86 lb (8.10 kg)
System volume 1739 cu in 941.63 cu in
Shipping weight* 28.79 lb (13.06 kg) 26.70 lb (12.11 kg)
Maximum supported
weight (desktop
orientation)
77.1 lb (35 kg) 77.1 lb (35 kg)
Shipping box dimensions
(H x W x D)
12.0 x 19.76 x 23.62 in 9.72 x 19.68 x 22.67 in
* Configured with 1 hard drive, 1 optical drive, no diskette drive, and no PCI card.
Power Supply 300W power supply – passive PFC 240W power supply – active PFC
Energy Efficient Power
Supply
300W 85% efficient power supply – active PFC 240W 85% efficient power supply – active PFC
Ports
USB 2.0 8 (2 front, 6 rear)
Serial 1 standard with 2
nd
optional
Parallel 1 optional
PS/2 1 keyboard, 1 mouse
Video analog for integrated graphics
DVI output available via ADD2 card in PCIe x16 connector
Support for Multi-Monitor available via ADD2 card in PCIe x16 connector or via PCIe graphics cards
Audio Integrated High Definition audio with internal speaker
Front – mic and headphone
Rear – input (supports microphone or line input), line out
NIC (RJ-45) Integrated Intel 82566DM Gigabit Network Connection Ethernet
MT SFF
Chipset Intel Q33 Express chipset X X
QuickSpecs
HP Compaq dc5800 Business PC
Standard Features and Configurable Components
