HP Compaq dc7600 MT Hardware Reference Guide

2–2 www.hp.com Hardware Reference Guide
Hardware Upgrades
Smart Cover Lock
✎
The Smart Cover Lock is an optional feature included on some
models only.
The Smart Cover Lock is a software-controllable cover lock,
controlled by the setup password. This lock prevents unauthorized
access to the internal components. The computer ships with the
Smart Cover Lock in the unlocked position. For more information
about locking the Smart Cover Lock, refer to the Desktop
Management Guide on the Documentation and Diagnostics CD.
Using the Smart Cover FailSafe Key
If you enable the Smart Cover Lock and cannot enter your password
to disable the lock, you will need a Smart Cover FailSafe Key to open
the computer cover. You will need the key to access the internal
computer components in any of the following circumstances:
■ Power outage
■ Startup failure
■ PC component (for example, processor or power supply) failure
■ Forgotten password
✎
The Smart Cover FailSafe Key is a specialized tool available from HP.
Be prepared; order this key before you need one.
To obtain a FailSafe Key:
■ Contact an authorized HP reseller or service provider. Order PN
166527-001 for the wrench-style key or PN 166527-002 for the
screwdriver bit key.
■ Refer to the HP Web site (www.hp.com) for ordering information.
■ Call the appropriate number listed in the warranty.

HP Compaq dc7600 MT Specifications

General

Memory	Up to 4 GB DDR2 SDRAM
Audio	Integrated High Definition Audio
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 2 PCI
Form Factor	Microtower
Processor	Intel Pentium 4 or Intel Celeron D
Chipset	Intel 945G Express
Hard Drive	40 GB to 160GB SATA
Optical Drive	DVD-ROM, DVD+/-RW
Graphics	Integrated Intel Graphics Media Accelerator 950
Networking	Integrated 10/100/1000 Ethernet
Ports	Serial, parallel, VGA, audio in/out
Operating System	Windows XP Professional, Windows XP Home
USB Ports	8 USB 2.0 (2 front, 6 rear)
