Hardware Reference Guide www.hp.com 2–11
Hardware Upgrades
DIMM Socket Locations
Item Description Socket Color
1 DIMM socket XMM1, Channel A Black
2 DIMM socket XMM2, Channel A White
3 DIMM socket XMM3, Channel B Black
4 DIMM socket XMM4, Channel B White
