HP Compaq dc7600 MT Hardware Reference Guide

2–20 www.hp.com Hardware Reference Guide
Hardware Upgrades
10. To install a new expansion card, slide the bracket on the end of
the card down into the slot on the back of the chassis and press
the card down firmly into the socket on the system board.
Installing an Expansion Card
✎
When you install an expansion card, make sure you press firmly on
the card so that the whole connector seats properly in the expansion
card socket.
11. Close the expansion card retention latch, making sure that it snaps
firmly into place.
12. Connect external cables to the installed card, if needed. Connect
internal cables to the system board, if needed. If the card requires
audio, connect the audio cable to the connector on the system
board labeled “Aux” (located towards the edge of the system
board in front of the PCI slots).
13. Replace the computer access panel.
14. If you normally lock the Smart Cover Lock, use Computer Setup
to relock the lock and enable the Smart Cover Sensor.

HP Compaq dc7600 MT Specifications

General

Memory	Up to 4 GB DDR2 SDRAM
Audio	Integrated High Definition Audio
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 2 PCI
Form Factor	Microtower
Processor	Intel Pentium 4 or Intel Celeron D
Chipset	Intel 945G Express
Hard Drive	40 GB to 160GB SATA
Optical Drive	DVD-ROM, DVD+/-RW
Graphics	Integrated Intel Graphics Media Accelerator 950
Networking	Integrated 10/100/1000 Ethernet
Ports	Serial, parallel, VGA, audio in/out
Operating System	Windows XP Professional, Windows XP Home
USB Ports	8 USB 2.0 (2 front, 6 rear)
