HP Compaq dc7700 DT

10. Lift the release tabs again (1) and pull the front bezel assembly out of the chassis (2).
Figure 2-5 Removing the Front Bezel
To replace the front bezel assembly:
1. Align the front bezel assembly with the front of the chassis and slide the assembly in. Stop about
1.3 cm (0.5 inch) away from the chassis.
Figure 2-6 Aligning the Front Bezel Assembly
ENWW Removing the Front Bezel Assembly 13
