Front Panel Components
Drive configuration may vary by model.
Table 1-1 Front Panel Components
1 Optical Drive 5 System Power LED
2 Microphone Connector 6 Hard Drive Activity Light
3 Headphone Connector 7 Dual-State Power Button
4 USB (Universal Serial Bus) Ports
NOTE An optical drive is a CD-ROM , CD-R/RW, DVD-ROM , DVD+R/RW, or CD-RW/DVD Combo drive.
2 Chapter 1 Product Features ENWW
