HP Compaq dc7700 DT

8. Push the release latch on the side of the optical drive toward the outside of the computer (1) and
slide the optical drive out of the computer through the front bezel (2).
Figure 2-17 Removing the Optical Drive
NOTE If you are not replacing the optical drive at this time, disconnect the optical drive cable
from the system board and store it carefully for future use.
26 Chapter 2 Hardware Upgrades ENWW
