3 Setting up the monitor
To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other
attached devices, and then follow the instructions below.
Unfolding the monitor pedestal base
NOTE: The L2206tm panel head model does not ship with a stand.
1. Lift the monitor from its box and place it face down on a flat surface.
2. Hold down the monitor base with one hand (1) then grasp the top of the stand with the other
hand and unfold the display head 90 degrees (2).
CAUTION: Do not touch the surface of the LCD panel. Pressure on the panel may cause non-
uniformity of color or disorientation of the liquid crystals. If this occurs, the screen will not recover to
its normal condition.
Figure 3-1 Unfolding the monitor pedestal base
NOTE: When the monitor is unfolded for the first time, the display head is locked from adjusting to a
full-height position. To adjust the display head to full height, press down on the display head to unlock
it, and then pull up on the display head to raise it to the full-height position. Refer to step 2 in
Adjusting the monitor on page 9.
Unfolding the monitor pedestal base 5
