HP Compaq LA1951G User Manual

Removing the Monitor Pedestal Base
You can remove the monitor panel from the pedestal base to install the panel on a wall, a swing arm,
or other mounting fixture.
CAUTION: Before beginning to disassemble the monitor, be sure the monitor is turned off and the
power and signal cables are both disconnected.
1. Disconnect and remove the signal and power cables from the back of the monitor.
2. Lay the monitor face down on a flat surface covered by a dry, clean cloth.
3. Remove the four screws on the back of the monitor that connect the monitor panel to the pedestal
base.
Figure 3-12 Removing the Pedestal Base
4. Lift up on the pedestal base to remove it from the monitor display head.
ENWW Removing the Monitor Pedestal Base 13

HP Compaq LA1951G Specifications

General

Display Size	19 inches
Resolution	1280 x 1024
Aspect Ratio	5:4
Panel Type	TN
Brightness	250 cd/m²
Contrast Ratio	1000:1
Response Time	5 ms
Viewing Angle	160° horizontal, 160° vertical
Connectivity	VGA, DVI-D
USB Ports	2 x USB 2.0
Weight	12.6 lbs (with stand)
