Altitude:
Operating
Storage
0 to 3657.6 m
0 to 12192 m
0 to 12,000 feet
0 to 40,000 feet
Power Consumption (maximum) <44 watts
Input Terminal One VGA connector with cable included;
one DVI connector with cable included
Recognizing Preset Display Resolutions
The display resolutions listed below are the most commonly used modes and are set as factory defaults.
This monitor automatically recognized these preset modes and they will appear properly sized and
centered on the screen.
LA1751g and LA1951g Models
Table B-3 Factory Preset Modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 × 480 31.469 59.940
2 720 × 400 31.469 70.087
3 800 × 600 37.879 60.317
4 1024 × 768 48.363 60.004
5 1280 × 960 60.00 60.00
6 1280 × 1024 63.98 60.02
Entering User Modes
The video controller signal may occasionally call for a mode that is not preset if:
●
You are not using a standard graphics adapter.
●
You are not using a preset mode.
It this occurs, you may need to readjust the parameters of the monitor screen by using the on-screen
display. Your changes can be made to any or all of these modes and saved in memory. The monitor
automatically stores the new setting, then recognized the new mode just as it does a preset mode. In
addition to the factory preset modes, there are 15 user modes that can be entered and stored.
Table B-2 LA1951g Specifications (continued)
ENWW Recognizing Preset Display Resolutions 35
