HP Compaq LA2205wg User Manual

Table A-8 Factory Preset Modes (continued)
4 1024 × 768 48.363 60.004
5 1280 × 960 60.00 60.00
6 1280 × 1024 63.981 60.02
7 1440 × 900 55.935 59.887
8 1600 × 1200 75.00 60.00
9 1680 × 1050 65.29 60.00
10 1920 × 1080 67.5 60.00
11 1920 × 1200 74.038 59.95
12 1920 × 1200 74.556 60.00
*
Preset 2 not supported on LA2405x model.
Entering User Modes
The video controller signal may occasionally call for a mode that is not preset if:
●
You are not using a standard graphics adapter.
●
You are not using a preset mode.
It this occurs, you may need to readjust the parameters of the monitor screen by using the on-screen
display. Your changes can be made to any or all of these modes and saved in memory. The monitor
automatically stores the new setting, then recognized the new mode just as it does a preset mode. In
addition to the factory preset modes, there are 15 (LA1905wg model), 20 (LA2205wg and LA22f
models), or 25 (LA2405wg and LA2405x models) user modes that can be entered and stored.
Energy Saver Feature
The monitors support a reduced power state. The reduced power state will be entered into if the
monitor detects the absence of either the horizontal sync signal and/or the vertical sync signal. Upon
detecting the absence of these signals, the monitor screen is blanked, the backlight is turned off, and
the power light is turned amber. When the monitor is in the reduced power state, the monitor will
utilize less than 2 watts of power. There is a brief warm up period before the monitor will return to its
normal operating mode.
Refer to the computer manual for instructions on setting energy saver features (sometimes called
power management features).
NOTE: The above power saver feature only works when connected to computers that have energy
saver features.
By selecting the settings in the monitor's Energy Saver utility, you can also program the monitor to
enter into the reduced power state at a predetermined time. When the monitor's Energy Saver utility
causes the monitor to enter the reduced power state, the power light blinks amber.
22 Appendix A Technical Specifications

HP Compaq LA2205wg Specifications

General

3D	No
Pixel pitch	0.282 x 0.282 mm
Display diagonal	22 \
Separate H/V sync	Yes
Display resolution	1680 x 1050 pixels
Contrast ratio (dynamic)	3000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewing angle, horizontal	160 °
Digital vertical frequency	50 - 76 Hz
Digital horizontal frequency	24 - 83 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1280 x 960, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
USB hub version	2.0
DVI-I ports quantity	0
USB Type-A downstream ports quantity	2
LED indicators	Power
Tilt angle range	-5 - 30 °
Height adjustment	120 mm
Panel mounting interface	- mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR
AC input voltage	100 - 240 V
Power consumption (off)	0.5 W
Power consumption (standby)	1 W
Power consumption (typical)	33 W
Power requirements	100 - 240V, 47/63Hz
Sync input impedance	75 Ω
Operating altitude	0 - 5000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	231 mm
Package width	591 mm
Package height	492 mm
Certification	EPEAT Gold, RoHS
Country of origin	China
Market positioning	Business
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	254.9 mm
Width (with stand)	511.2 mm
Height (with stand)	373.5 mm
Depth (without stand)	62 mm
Width (without stand)	511 mm
Height (without stand)	334 mm
Weight (without stand)	6820 g
