NOTE: To view information on the screen in portrait mode, you will need to install the Pivot Pro

software included on the software and documentation CD. The position of the OSD menu can

also be rotated to portrait mode. To rotate the OSD menu, access the OSD menu by pressing

the Menu button on the front panel, select OSD Control, then select Rotate OSD.

Turning on the Monitor

1. Press the power button on the computer to turn it on.

2. Press the power button on the front of the monitor to turn it on.

CAUTION: Burn-in image damage may occur on monitors that display the same static image on

screen for a prolonged period of time.* To avoid burn-in image damage on the monitor screen, you

should always activate a screen saver application or turn off the monitor when it is not in use for a

prolonged period of time. Image retention is a condition that may occur on all LCD screens. Monitors

with a “burned-in image” are not covered under the HP warranty.

* A prolonged period of time is 12 consecutive hours of non-use.

NOTE: If pressing the power button has no effect, the Power Button Lockout feature may be

enabled. To disable this feature, press and hold the monitor power button for 10 seconds.

NOTE: You can disable the power LED in the OSD menu. Press the Menu button on the front of the

monitor, then select Management > Bezel Power LED > Off.

When the monitor is powered on, a Monitor Status message is displayed for five seconds. The

message shows which input (DisplayPort, DVI, or VGA) is the current active signal, the status of the

auto-switch source setting (On or Off; factory default is On), the default source signal (factory default

is DisplayPort), the current preset display resolution, and the recommended preset display resolution.

The monitor automatically scans the signal inputs for an active input and uses that input for the

display. If two or more inputs are active, the monitor will display the default input source. If the default

source is not one of the active inputs, then the monitor will display the highest ranking priority input in

the following order: DisplayPort, DVI, then VGA. You can change the default source in the OSD by

pressing the front panel menu button and selecting Source Control > Default Source.

Turning on the Monitor 9

Other manuals for HP Compaq LA2205wg

Questions and Answers:

Need help?

Do you have a question about the HP Compaq LA2205wg and is the answer not in the manual?

General

3D	No
Pixel pitch	0.282 x 0.282 mm
Display diagonal	22 \
Separate H/V sync	Yes
Display resolution	1680 x 1050 pixels
Contrast ratio (dynamic)	3000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewing angle, horizontal	160 °
Digital vertical frequency	50 - 76 Hz
Digital horizontal frequency	24 - 83 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1280 x 960, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
USB hub version	2.0
DVI-I ports quantity	0
USB Type-A downstream ports quantity	2
LED indicators	Power
Tilt angle range	-5 - 30 °
Height adjustment	120 mm
Panel mounting interface	- mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR
AC input voltage	100 - 240 V
Power consumption (off)	0.5 W
Power consumption (standby)	1 W
Power consumption (typical)	33 W
Power requirements	100 - 240V, 47/63Hz
Sync input impedance	75 Ω
Operating altitude	0 - 5000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	231 mm
Package width	591 mm
Package height	492 mm
Certification	EPEAT Gold, RoHS
Country of origin	China
Market positioning	Business
Sustainability certificates	ENERGY STAR
