7 Screw listing
This section provides specification and reference information for the screws and screw locks used in
the device. All screws listed in this section are available in the Screw Kit, spare part number 537620-001;
or in the Display Screw Kit, spare part number 538510-001.
Phillips PM1.5×1.0 screw
Color Quantity Length Thread Head diameter
Silver 6 1.0 mm 1.5 mm 1.0 mm
Where used: 4 screws that secure the heat sink to the system board
Phillips PM1.5×1.0 screw 97
