6. If it is necessary to replace the display panel, perform the following steps:
a. Remove the 7 Phillips PM2.0×3.0 screws that secure the display panel to the display
enclosure.
b. Lift the display panel up from the display enclosure (1).
c. Disconnect the webcam cable (2) from the system board (2)
d. Remove the display panel (3) from the display enclosure.
7. If it is necessary to replace the speaker assembly, perform the following steps:
a. Remove the three Phillips PM2.0×3.0 screws (1) that secure the speaker assembly to the
display enclosure.
Component replacement procedures 79
