HP Compaq NC4000 New Features

3
There are three classes of information that you can obtain from the client computers.
• Client inventory: Includes detailed client information such as the chassis serial number, computer
model number, memory size, operating system, CPU identification, and many more inventory items.
With HPCM 6.1, you can even gather basic information for your non-HP client computers.
• Health monitoring: The health monitoring capabilities of HPCM allow you to select from a set of
client-side events, such as a chassis intrusion, disk drive error, battery status, thermal changes, and
“walking assets” such as new or missing PCs, memory, battery, disk drives, CPUs, and monitors.
When one of these events occurs, the client alerts the HPCM Server, which takes the predefined
action that you have specified, such as sending you an e-mail alert. You can also monitor the status
of these events using one of the pre-configured reports.
• Diagnostic information: Client diagnostics are performed on the memory, CPU, storage devices,
and I/O devices. The diagnostic results are returned from each client computer to the HPCM Server
for display.
With HPCM, the user can perform the following types of operations on the client computers from the
Altiris Console on the HPCM Server.
System software installation: HPCM allows you to install or update system software on the client
computers from a central Filestore on the HPCM Server. Software installations are performed only
on those client computers that match the hardware and software criteria that you specify. For
example, you can download a network driver or audio driver SoftPaq to the HPCM Server and then
use HPCM to schedule the installation of the drivers on the client computers. HPCM will install the
drivers only on those client computers that contain hardware supported by each particular driver.
SoftPaqs
SoftPaqs are Web-downloadable software packages made available by HP
to ensure that our customers have the most up-to-date and highest-quality
system software. Normally, a SoftPaq would be downloaded to each client
machine and installed separately. With HPCM, SoftPaq installation can be
configured to happen automatically and remotely across all client
computers.
BIOS Flash: HPCM can be used to upgrade the BIOS firmware on client computers. HPCM can
a
utomatically and remotely update the BIOS on any client computer. You can use it to flash a single
computer or a group of computers. It also allows you to view reports for computers not receiving
updates or to see where installation failed.
Manage HP ProtectTools enabled clients: Identify and inventory HP client computers that
include the ProtectTools embedded security chip. Use the HP Client Manager console to remotely
initialize the security chip on your computers, saving time in setting-up a more secure client
infrastructure. Note: This requires HPCM 6.1 SP1.
Change BIOS settings: When booting a computer you can press the F10 key to pause the boot
process in order to change the BIOS settings, such as the Storage Options or the Boot Order, as
shown in Figure 2. After Microsoft Windows has booted on the client computers, you can use
HPCM to change the BIOS settings simultaneously on multiple client computers without having to
visit each computer individually.

HP Compaq NC4000 Specifications

General

Processor cache	1 MB
Processor model	-
Processor frequency	1.4 GHz
Processor cache type	L2
Processor front side bus	400 MHz
Processor core voltage (AC)	0.956 - 1.388 V
HDD speed	5400 RPM
HDD interface	Ultra-ATA/100
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	40 GB
Compatible memory cards	SD
Number of HDDs installed	1
Pixel pitch	0.264 x 0.264 mm
Display diagonal	12.1 \
Display brightness	130 cd/m²
Display resolution	1024 x 768 pixels
Native aspect ratio	4:3
Display number of colors	16.78 million colors
Type	PC
Modem speed	56 Kbit/s
Power supply type	AC/DC
Power requirements	90 - 264V, 47/63Hz
Wireless technology	Wi-Fi
Graphics card family	AMD
Compatible operating systems	Windows XP
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots	2x SO-DIMM
Internal memory	0.25 GB
Internal memory type	DDR-SDRAM
Maximum internal memory	1 GB
Audio system	PS
Pointing device	Touchpad
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows XP Professional
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	2
Firewire (IEEE 1394) ports	0
Cable lock slot type	Kensington
AC adapter power	65 W
Number of battery cells	6
Operating shock	40 G
Operating altitude	0 - 3048 m
Non-operating shock	240 G
Operating vibration	0.5 G
Non-operating altitude	0 - 9144 m
Non-operating vibration	1 G
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	UL, CSA, VDE/TUV
Product color	Black, Silver
Country of origin	China

Weight and Dimensions

Depth	233.7 mm
Width	279.4 mm
Height	27.9 mm
Weight	1590 g
