HP Compaq nc6000 Quickspecs

Frequency Band
Frequency BandFrequency Band
Frequency Band 2.4 and 5 GHz
Data Rates
Data RatesData Rates
Data Rates 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
ModulationModulation
Modulation Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
SecuritySecurity
Security Supports 64- and 128-bit WEP, WPA, hardware-accelerated AES, 802.1x
authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP
Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program).
Sub-channels
Sub-channelsSub-channels
Sub-channels Multinational support with frequency bands and channels compliant to local
regulations.
Media Access Protocol
Media Access ProtocolMedia Access Protocol
Media Access Protocol CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Network ArchitectureNetwork Architecture
Network Architecture
Models
ModelsModels
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
RoamingRoaming
Roaming IEEE 802.11 compliant roaming between 802.11a and 802.11b/g access
points
Output Power
Output PowerOutput Power
Output Power 802.11b: 17 dBM (typical)
802.11g: 15 dBM (typical)
Power Consumption
Power ConsumptionPower Consumption
Power Consumption Transmit: 2.0 W (max)
Receive: 1.5 W (max)
Sleep mode: 20 mW (max)
Power Management
Power ManagementPower Management
Power Management ACPI compliant power management
802.11 Compliant Power Saving Mode
Power Saving Mode selectable through the configuration utility
Receiver Sensitivity*
Receiver Sensitivity*Receiver Sensitivity*
Receiver Sensitivity* 54 Mbps: -70 dBm to 1 Mbps: -90 dbm
Antenna type
Antenna typeAntenna type
Antenna type High efficiency dual band antenna with polarization diversity, mounted in the
display enclosure
Range
RangeRange
Range 802.11a – Typical 500 feet – Outdoors Open Area
150 feet – Indoor, Office-environment
802.11 b – Typical 1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical 1000 feet – Outdoor Open Area
200 feet – Indoor, Office environment
Form Factor
Form FactorForm Factor
Form Factor MiniPCI Type IIIA
Weight
WeightWeight
Weight 0.036 lb (16.5 g)
Dimensions
DimensionsDimensions
Dimensions 0.19 x 2.00 x 2.35 in (4.8 x 50.95 x 59.75 mm)
Operating Voltage
Operating VoltageOperating Voltage
Operating Voltage 3.3v
Temperature
TemperatureTemperature
Temperature Operating
OperatingOperating
Operating
Non-operating
Non-operatingNon-operating
Non-operating
32° to 122° F (0° to 50° C)
-14° to 158° F (-10° to 70° C)
Humidity
HumidityHumidity
Humidity Operating
OperatingOperating
Operating
Non-operating
Non-operatingNon-operating
Non-operating
10% to 90%
5% to 95%
Altitude
AltitudeAltitude
Altitude Operating
OperatingOperating
Operating
Non-operating
Non-operatingNon-operating
Non-operating
0 to 15,000 ft (4,572 m)
0 to 40,000 ft (12,192 m)
QuickSpecs
HP Compaq nc6000 Business Notebook
HP Compaq nc6000 Business NotebookHP Compaq nc6000 Business Notebook
HP Compaq nc6000 Business Notebook
Technical Specifications
DA - 11794 North America — Version 41 — August 1, 2005 Page 28

HP Compaq nc6000 Specifications

General

Display	LCD
TV-in port	No
Modem speed	56 Kbit/s
Internal modem	Yes
Multi-bay devices	Tweede batterij, tweede vaste schijf, diskettedrive
Power supply type	AC 90~264V, 1.6A, 47-63 Hz, 4/50 kV
Dimensions (WxDxH)	318 x 262 x 34 mm
Wireless technology	IEEE 802.11b/g, Bluetooth
TV-out type	S-Video
Charging port type	DC-in jack
PS/2 ports quantity	0
USB 2.0 ports quantity	2
CardBus PCMCIA slot type	Type III
Pointing device	Touchpad
HDD speed	4200 RPM
Optical drive type	DVD-ROM
Total storage capacity	40 GB
Compatible memory cards	SD
Audio system	Premier Sound 16-bits
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 90 %
Processor cache	1 MB
Processor frequency	1.7 GHz
Processor cache type	L2
Internal memory	0.5 GB
Internal memory type	DDR-SDRAM
Maximum internal memory	2 GB
Display diagonal	14.1 \
Display resolution	1024 x 768 pixels
Native aspect ratio	4:3
Discrete graphics card model	AMD Mobility Radeon 9600
Maximum graphics card memory	0.064 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Motherboard chipset	Intel® 855PM
Bundled software	Acrobat Reader
Operating system installed	Windows XP Professional
Number of battery cells	6
Country of origin	China

Weight and Dimensions

Depth	262 mm
Width	318 mm
Height	34 mm
Weight	2300 g
