HP Compaq nc6000 Quickspecs

Processors
ProcessorsProcessors
Processors Intel Pentium M processor 755* – 2.0GHz, 2MB L2 cache, 400 MHz Front Side Bus (FSB)
Intel Pentium M processor 745 – 1.8GHz, 2MB L2 cache, 400MHz Front Side Bus (FSB)
Intel Pentium M processor 735 – 1.7GHz, 2MB L2 cache, 400MHz Front Side Bus (FSB)
Intel Pentium M processor 725 – 1.6GHz, 2MB L2 cache, 400MHz Front Side Bus (FSB)
Intel 855PM Chipset
NOTE:
NOTE:NOTE:
NOTE: Intel Pentium M Processors support enhanced Intel SpeedStep™ technology. Processor speed
denotes maximum performance mode; processors will run at approximately 600Mhz in battery
optimization mode.
* Intel's numbering is not a measurement of higher performance.
Operating System
Operating SystemOperating System
Operating System Microsoft Windows XP Professional
Microsoft Windows XP Home (model dependent)
Chipset
ChipsetChipset
Chipset Intel 855PM Chipset with 400MHz processor side bus and enhanced SpeedStep technology
Display
DisplayDisplay
Display Internal 14.1-inch TFT XGA with (1024x768) resolution (16M colors)
14.1-inch TFT SXGA+ with (1400x1050) resolution (16M colors)
External Up to 32-bit per pixel color depth
Supports 640 x 480, 800 x 600, 1024 x 768, 1280 x 768, 1280 x 1024,
or 1600 x 1200 resolutions up to 100-Hz refresh rate, dependent upon
monitor capability, and resolution and color depth settings
Memory
MemoryMemory
Memory Standard 256-MB or 512-MB (333-MHz) DDR SDRAM (SODIMM in slot 1)
Maximum 2048-MB (333-MHz) DDR SDRAM
(1024-MB SODIMMs in slots 1 and 2)
NOTE:
NOTE: NOTE:
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend
HP branded memory to ensure compatibility.
Communications
CommunicationsCommunications
Communications 10/100/1000 NIC
High speed 56K modem with digital line guard
NOTE:
NOTE: NOTE:
NOTE: Designed only to allow faster downloads from high speed 56K modem compliant sources.
Maximum achievable download transmission rates currently do not reach 56 KB/s, and will vary with line
conditions.
NOTE:
NOTE: NOTE:
NOTE: Modem availability is subject to country regulatory approval.
Keyboard
KeyboardKeyboard
Keyboard The 101/102-key compatible keyboard features an industry standard, full-width layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, 3x2 editing keys, both left and
right control and alt keys, and 11 function keys. The US layout has 84 keys and the International layout
85 keys. Other features include an integrated numeric keypad, hotkeys for instant access to power
conservation, volume, brightness, and other features, 19.05 mm x 19.05 mm key pitch (center-to-center
spacing), 2.5 mm stroke, comfort-dished keycaps, and bright key legends for improved visibility in low
light conditions.
QuickSpecs
HP Compaq nc6000 Business Notebook
HP Compaq nc6000 Business NotebookHP Compaq nc6000 Business Notebook
HP Compaq nc6000 Business Notebook
Standard Features
DA - 11794 North America — Version 41 — August 1, 2005 Page 3

HP Compaq nc6000 Specifications

General

Display	LCD
TV-in port	No
Modem speed	56 Kbit/s
Internal modem	Yes
Multi-bay devices	Tweede batterij, tweede vaste schijf, diskettedrive
Power supply type	AC 90~264V, 1.6A, 47-63 Hz, 4/50 kV
Dimensions (WxDxH)	318 x 262 x 34 mm
Wireless technology	IEEE 802.11b/g, Bluetooth
TV-out type	S-Video
Charging port type	DC-in jack
PS/2 ports quantity	0
USB 2.0 ports quantity	2
CardBus PCMCIA slot type	Type III
Pointing device	Touchpad
HDD speed	4200 RPM
Optical drive type	DVD-ROM
Total storage capacity	40 GB
Compatible memory cards	SD
Audio system	Premier Sound 16-bits
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 90 %
Processor cache	1 MB
Processor frequency	1.7 GHz
Processor cache type	L2
Internal memory	0.5 GB
Internal memory type	DDR-SDRAM
Maximum internal memory	2 GB
Display diagonal	14.1 \
Display resolution	1024 x 768 pixels
Native aspect ratio	4:3
Discrete graphics card model	AMD Mobility Radeon 9600
Maximum graphics card memory	0.064 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Motherboard chipset	Intel® 855PM
Bundled software	Acrobat Reader
Operating system installed	Windows XP Professional
Number of battery cells	6
Country of origin	China

Weight and Dimensions

Depth	262 mm
Width	318 mm
Height	34 mm
Weight	2300 g
