HP Compaq nc6000 Quickspecs

1.
2.
3.
4.
Receiver Sensitivity
Receiver SensitivityReceiver Sensitivity
Receiver Sensitivity
3
33
3
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
Antenna type
Antenna typeAntenna type
Antenna type High efficiency dual band antenna with polarization diversity, mounted in the
display enclosure
Range
RangeRange
Range 802.11 b – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
Form Factor
Form FactorForm Factor
Form Factor MiniPCI Type IIIB
Weight
WeightWeight
Weight 0.026 lb (11.75 g) (max)
Dimensions
DimensionsDimensions
Dimensions 0.20 x 1.75 x 2.34 in (4.9 x 44.6 x 59.8 mm)
Operating Voltage
Operating VoltageOperating Voltage
Operating Voltage 3.3v
Temperature
TemperatureTemperature
Temperature Operating
Non-operating
32° to 158° F (0° to 70° C)
-40° to 176° F (-40° to 80° C)
Humidity
HumidityHumidity
Humidity Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
AltitudeAltitude
Altitude Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
Configuration UtilityConfiguration Utility
Configuration Utility
4
44
4
Choice of Configuration Utility:
Intel PROSet for Microsoft Windows 2000 or XP (required for Cisco
Compatible Extensions support)
Microsoft Windows XP Wireless Network Connection Manager
Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN may also
be compatible with certain third-party software supplicants.
Bluetooth by HP
Bluetooth by HPBluetooth by HP
Bluetooth by HP Name
NameName
Name HP Integrated module with Bluetooth wireless technology
Bluetooth Specification
Bluetooth SpecificationBluetooth Specification
Bluetooth Specification 1.2 Compliant
Dimensions
DimensionsDimensions
Dimensions 1.02 x 0.55 x 0.22 in (26 x 14 x 5.7 mm)
Frequency Band
Frequency BandFrequency Band
Frequency Band 2402 to 2480 MHz
Number of available
Number of availableNumber of available
Number of available
channels
channelschannels
channels
79 (1 MHz) available channels
Data Rates and
Data Rates andData Rates and
Data Rates and
throughput
throughputthroughput
throughput
1 Mbps data rate; throughput up to 720 Kbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Asynchronous Connection Less links 723.2 kbps/57.6 kbps asymmetric or
433.9 kbps symmetric
Transmit Power
Transmit PowerTransmit Power
Transmit Power -6 dBm to 4 dBm (Bluetooth Class II)
Receiver Sensitivity
Receiver SensitivityReceiver Sensitivity
Receiver Sensitivity Better than -80 dBM at 0.1 % raw bit error rate
Power Consumption
Power ConsumptionPower Consumption
Power Consumption Peak (Tx) 264 mW
Peak (Rx) 231 mW
Sleep <1 mW
Antenna
AntennaAntenna
Antenna Internally integrated within module
Range
RangeRange
Range Up 33 ft (10 m)
QuickSpecs
HP Compaq nc6000 Business Notebook
HP Compaq nc6000 Business NotebookHP Compaq nc6000 Business Notebook
HP Compaq nc6000 Business Notebook
Technical Specifications
DA - 11794 North America — Version 41 — August 1, 2005 Page 31

HP Compaq nc6000 Specifications

General

Display	LCD
TV-in port	No
Modem speed	56 Kbit/s
Internal modem	Yes
Multi-bay devices	Tweede batterij, tweede vaste schijf, diskettedrive
Power supply type	AC 90~264V, 1.6A, 47-63 Hz, 4/50 kV
Dimensions (WxDxH)	318 x 262 x 34 mm
Wireless technology	IEEE 802.11b/g, Bluetooth
TV-out type	S-Video
Charging port type	DC-in jack
PS/2 ports quantity	0
USB 2.0 ports quantity	2
CardBus PCMCIA slot type	Type III
Pointing device	Touchpad
HDD speed	4200 RPM
Optical drive type	DVD-ROM
Total storage capacity	40 GB
Compatible memory cards	SD
Audio system	Premier Sound 16-bits
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 90 %
Processor cache	1 MB
Processor frequency	1.7 GHz
Processor cache type	L2
Internal memory	0.5 GB
Internal memory type	DDR-SDRAM
Maximum internal memory	2 GB
Display diagonal	14.1 \
Display resolution	1024 x 768 pixels
Native aspect ratio	4:3
Discrete graphics card model	AMD Mobility Radeon 9600
Maximum graphics card memory	0.064 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Motherboard chipset	Intel® 855PM
Bundled software	Acrobat Reader
Operating system installed	Windows XP Professional
Number of battery cells	6
Country of origin	China

Weight and Dimensions

Depth	262 mm
Width	318 mm
Height	34 mm
Weight	2300 g
