Removal and Replacement Procedures
Maintenance and Service Guide 5–27
6. Remove the 4 PM1.5×4.0 screws 1 that secure the LED
board to the switch cover.
7. Remove the LED board 2.
Removing the LED Board
Reverse the above procedure to install the LED board.
