5–24 Maintenance and Service Guide
Removal and Replacement Procedures
5.10 Switch Cover
1. Prepare the notebook for disassembly (Section 5.3).
2. Remove the keyboard (Section 5.9).
3. Turn the notebook upside down with the rear panel
toward
you.
4. Remove the 2 T8M2.0×2.0 screws that secure the switch
cover to the notebook.
Removing the Switch Cover Screws
Switch Cover Spare Part Number Information
Switch covers
For use with full-featured models
For use with defeatured models
378232-001
378242-001
