Product Description
Maintenance and Service Guide 1–21
4 Memory module
compartment
Mini PCI compartment
Contains 2 memory slots that support
replaceable memory modules. The
number of preinstalled memory
modules varies by notebook model.
Holds an optional wireless LAN device.
Ä
To prevent an unresponsive
system and the display of a
warning message, install only a
Mini PCI device authorized for
use in your notebook by the
governmental agency that
regulates wireless devices in your
country. If you install a device
and then receive a warning
message, remove the device to
restore notebook functionality.
Then contact Customer Care.
5 Hard drive bay Holds the primary hard drive.
6 Primary battery release
latch
Releases the primary battery pack from
the battery bay.
7 Travel battery connector Connects an optional travel battery.
8 Fan Provides airflow to cool internal
components.
Ä
To prevent overheating, do not
obstruct fans. Do not allow a hard
surface, such as a printer, or a
soft surface, such as pillows,
thick rugs, or clothing, to block
airflow.
Table 1-8
Bottom Components
(Continued)
Item Component Function
