Removal and Replacement Procedures
Maintenance and Service Guide 5–13
3. Loosen the PM2.0×4.0 screw 1 that secures the memory
module/Mini PCI compartment cover to the notebook.
4. Lift the rear edge of the cover up and swing it toward you 2.
5. Remove the memory module/Mini PCI compartment cover.
✎
The memory module/Mini PCI compartment cover is included
in the Miscellaneous Plastics Kit, spare part number
378236-001.
Removing the Memory Module/Mini PCI Compartment Cover
