6–42 Maintenance and Service Guide
Removal and Replacement Procedures
4. Turn the notebook top-side up with the front toward you.
5. Release the ZIF connector to which the TouchPad cable 1 is
connected and disconnect the TouchPad cable from the
system board.
6. Disconnect the fingerprint reader cable 2 from the
system board.
7. Remove the Torx T8M2.5×7.0 screw 3 that secures the
top cover to the notebook.
Disconnecting the Top Cover Cables and Removing the
Top Cover Screw
