C–2 Maintenance and Service Guide
Screw Listing
Phillips PM2.5×6.0 Screw Locations
Table C-1
Phillips PM2.5×6.0 Screw
Color Qty. Length Thread
Head
Width
Black 4 6.0 mm 2.5 mm 4.0 mm
Where used:
1 Two screws that secure the hard drive cover to the notebook (screws are
captured on the cover by C clips; documented in Section 6.4)
2 Two screws that secure the memory module compartment cover to the
notebook (screws are captured on the cover by C clips; documented in
Section 6.7)
mm
