HP Compaq nx6125 - Page 194

C–8 Maintenance and Service Guide
Screw Listing
Torx T8M2.5×4.0 Screw Location
Table C-5
Torx T8M2.5×4.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 11 4.0 mm 2.5 mm 5.0 mm
Where used:
One screw that secures the power switch board to the switch cover
(documented in Section 6.10)
mm
