C–12 Maintenance and Service Guide
Screw Listing
Torx T8M2.5×7.0 Screw Locations
Table C-6
Torx T8M2.5×7.0 Screw
Color Qty. Length Thread
Head
Width
Black 13 7.0 mm 2.5 mm 5.0 mm
Where used:
1 Three screws that secure the fan to the notebook (documented in
Section 6.12)
2 Four screws that secure the heat sink to the notebook (documented in
Section 6.13)
mm
