HP Compaq NX9420 Security Guide

1 Protecting the computer
NOTE: Security solutions are designed to act as deterrents. These deterrents may not prevent a
product from being mishandled or stolen.
NOTE: Your computer supports CompuTrace, which is an online-security-based tracking and recovery
service. If the computer is stolen, CompuTrace can track the computer if the unauthorized user accesses
the Internet. You must purchase the software and subscribe to the service in order to use CompuTrace.
For information about ordering the CompuTrace software, see the HP Web site at
http://www.hpshopping.com.
Security features provided with your computer can protect the computer, personal information, and data
from a variety of risks. The way you use your computer will determine which security features you need
to use.
The Windows® operating system offers certain security features. Additional security features are listed
in the following table. Most of these additional security features can be configured in the Computer Setup
utility (referred to hereafter as Computer Setup).
To protect against Use this security feature
Unauthorized use of the computer
●
Power-on authentication using passwords or smart cards
●
HP ProtectTools Security Manager
Unauthorized access to Computer Setup (f10) Setup password in Computer Setup*
Unauthorized access to the contents of a hard drive DriveLock password in Computer Setup*
Unauthorized reset of Computer Setup (f10) passwords Stringent security feature in Computer Setup*
Unauthorized startup from an optical drive, diskette drive, or
internal network adapter
Boot options feature in Computer Setup*
Unauthorized access to a Windows user account HP ProtectTools Security Manager
Unauthorized access to data
●
Firewall software
●
Windows updates
●
HP ProtectTools Security Manager
Unauthorized access to Computer Setup settings and other
system identification information
Setup password in Computer Setup*
Unauthorized removal of the computer Security cable slot (used with an optional security cable)
*Computer Setup is a non-Windows utility accessed by pressing f10 when the computer is turned on or restarted. When using
Computer Setup, you must use the keys on your computer to navigate and make selections.
1

HP Compaq NX9420 Specifications

General

HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Total storage capacity	100 GB
Display diagonal	17 \
AC adapter power	90 W
Audio system	HP Premier Sound high-definition Audio 24-bits audio DAC, Digital EQ
Number of built-in speakers	2
Bus type	FSB
Stepping	C0
Tjunction	100 °C
Cache external	2048 KB
Processor cache	2 MB
Processor model	T2400
System bus rate	- GT/s
Processor family	Intel® Core™ Duo
Processor series	Intel Core Duo T2000 Series
Processor socket	Socket 478
Processor codename	Yonah
Processing Die size	90 mm²
Processor frequency	1.83 GHz
Processor cache type	L2
Processor technology	Intel Centrino Duo Mobile
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	667 MHz
Processor operating modes	32-bit
ECC supported by processor	No
Thermal Design Power (TDP)	31 W
CPU multiplier (bus/core ratio)	11
Number of Processing Die Transistors	151 M
Storage temperature (T-T)	-40 - 80 °C
Operating temperature (T-T)	0 - 80 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 95 %
Memory slots	2x SO-DIMM
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Internal modem	Yes
Expansion slots	1 Type I/II PC Card slot supports 32-bit CardBus, 16-bit cards, 7 in 1 media reader: Secure Digital, MultiMediaCard, Memory Stick, Stick Pro or Stick Duo, Smart Media and xD memory cards
Dimensions (WxDxH)	33 x 393 x 275 mm
Wireless technology	Intel Wireless LAN 802.11a/b/g, MOW2, Bluetooth
Diskette drive memory	No MB
Video card features	ATI Mobility Radeon X1600
Bundled software	Microsoft Windows Media Player 10, Microsoft Direct X9 Adobe Acrobat Reader, HP software voor sneltoetsen, HP Wireless Assistant, HP ProtectTools, HP Backup- en recoveryoplossing, HP Mobile printerdriver, HP OpenView Radia Management Agent, InterVideo WinDVD
Operating system installed	Windows XP Professional
Motherboard chipset	Intel® 945PM Express
Battery life (max)	4 h
Number of battery cells	8
Networking features	Broadcom Gigabit (10/100/1000 NIC) PCI Express Ethernet controller
Cable lock slot type	Kensington
Discrete graphics card model	AMD Mobility Radeon X1600
Maximum graphics card memory	0.256 GB
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
CardBus PCMCIA slot type	Type II
Firewire (IEEE 1394) ports	1
Processor ARK ID	27235
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	393 mm
Width	33 mm
Height	275 mm
Weight	3350 g
