Removal and Replacement Procedures
Maintenance and Service Guide 5–31
11. Remove the six rubber screw covers 1 and 2 and the
six Phillips PM2.5×7.0 screws 3 that secure the display
bezel to the display assembly.
✎
The rubber screw covers are available in the Display Screw Kit,
spare part number 435788-001.
The four rubber screw covers 1 on the top edge of the display
bezel are a different size and shape than the two rubber screw
covers 2 on the bottom edge of the display bezel.
Removing the Display Bezel Screws
