5–38 Maintenance and Service Guide
Removal and Replacement Procedures
✎
The display hinges are available in the Display Hinge Kit,
spare part number 407797-001.
24. If it is necessary to replace the display hinges, remove the
four Phillips PM2.0×4.0 screws 1 that secure each hinge
to the display panel.
25. Remove the display hinges 2.
Removing the Display Hinges
