Removal and Replacement Procedures
Maintenance and Service Guide 5–55
4. Remove the four silver Phillips PM2.5×4.0 screws 1 and the
two Phillips PM2.5×5.0 screws 2 that secure the TouchPad
bracket to the top cover.
5. Remove the TouchPad bracket 3.
✎
The TouchPad bracket is available using spare part number
407812-001.
Removing the TouchPad Bracket
