5–56 Maintenance and Service Guide
Removal and Replacement Procedures
6. Remove the display release button swing arm 1 from the
top cover.
7. Push and hold the display release button 2.
8. Remove the display release button 3 and springs 4 from
the top cover.
Removing the Display Release Button Assembly
Reverse the above procedure to install the display release
button assembly.
