Front Bezel
Description Spare part number
Front bezel 695080-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 48).
2. Remove the access panel (
Computer Access Panel on page 50).
3. Lift up the three tabs on the side of the bezel (1), then rotate the bezel off the chassis (2).
Figure 7-3 Removing the Front Bezel
To install the front bezel, reverse the removal procedure.
Front Bezel 51
