SFF
MT
Storage Drive Support
SFF
MT
MCR
ODD
HDD
MCR
ODD
HDD
# of supported
devices
1 1 2 1 2 2
Drive position
1 2
1,3
3
1,2 4,5
Controller
Hard Drive Controller
These systems provide four serial ATA (SATA) interfaces that support transfer rates up to 6.0
Gb/s (for ports 0 and 1, 3 Gb/s on all others). These systems can also support an external SATA
(eSATA) device through an optional bracket/cable assembly.
SATA Interfaces
2 ea. SATA 3.0
1 ea. SATA 2.0
1 ea. eSATA
Host SATA Controller
Advanced Host Controller Interface (AHCI) Revision 1.2. The specification includes a description
of the hardware/software interface between system software and the host controller hardware.
QuickSpecs
HP Compaq Pro 6305 Business PC
Technical Specifications – Hard Disk and Solid State Storage
DA - 14425 North America — Version 21 — December 2, 2013
Page 24
