HP dc7900 - Convertible Minitower PC Hardware Reference Guide

Front Panel Components
Drive configuration may vary by model.
Figure 1-2 Front Panel Components
Table 1-1 Front Panel Components
1 5.25-inch Optical Drives 8 5.25-inch Bay for Optional Drives
2
2 Optical Drive Activity Lights 9 Diskette Drive Activity Light (optional)
3 3.5-inch Diskette Drive (optional)
1
10 Diskette Eject Button (optional)
4 Dual-State Power Button 11 Power On Light
5 Hard Drive Activity Light 12 Headphone Connector
6 Microphone Connector 13 USB (Universal Serial Bus) Ports
7 Optical Drive Eject Buttons
CAUTION: The bottom 5.25-inch drive bay has a shorter depth than the upper two bays. The bottom bay supports
a half-height drive or other device that is no more than 14.5 cm (5.7 inches) in depth. Do not try to force a larger drive,
such as an optical drive, into the bottom bay. This could cause damage to the drive and the system board. The use
of unnecessary force when installing any drive into the drive bay may result in damage to the drive.
1
Some models are configured with a media card reader in the external 3.5-inch drive bay. Other models have a bezel blank
covering this bay.
2
Some models are configured with a media card reader in the external 5.25-inch drive bay. Other models have a bezel blank
covering this bay.
2 Chapter 1 Product Features ENWW

HP dc7900 - Convertible Minitower PC Specifications

General

Chipset	Intel Q45 Express
Memory	Up to 16 GB DDR2 SDRAM
Audio	Integrated High Definition Audio
Form Factor	Convertible Minitower
Processor	Intel Core 2 Duo, Core 2 Quad, Pentium Dual-Core
Storage	SATA Hard Drives
Graphics	Intel Graphics Media Accelerator 4500, optional discrete graphics
Optical Drive	DVD-ROM, DVD+/-RW
Network	Integrated Intel Gigabit Network Connection
Ports	USB 2.0, serial, parallel, audio in/out
Expansion Slots	PCI, PCIe x1, PCIe x16
Operating System	Windows Vista, Windows 7
