6. Front panel
7. Spindle
8. Blue removable paper stop
9. Bin
10. Ink cartridge drawer
11. Spindle lever
12. Paper load lever
Rear view
1. Quick Reference Guide holder
2. Power socket and on/off switch
3. Sockets for communication cables and optional accessories
The printer's main components [4500]
NOTE This topic applies to the HP Designjet 4500 Printer series only.
The following front and rear views of the printer illustrate the main components.
4 Chapter 1 Introduction ENWW
Introduction
