8. Ensure there is no space between the roll and the blue stop.
If you are a regular user of different paper types, you can change rolls more quickly if you pre-load rolls
of different paper types on different spindles. Extra spindles are available for purchase.
Load a roll into the printer [4500]
NOTE This topic applies to the HP Designjet 4500 Printer series only.
To start this procedure you need to have a roll loaded on the spindle. See
Load a roll onto the
spindle [4500].
1.
At the printer's front panel, select the
icon, then Paper load > Load roll 1 or Load roll 2.
Hint This step is optional. You may skip it and start the loading process without using
the front panel, by pulling out the drawer as shown below.
ENWW Load a roll into the printer [4500] 31
How do I... (paper topics)
